      Engineer class chain

      current location:Home > Products > Chain > Engineer class chain

      • Heavy Duty Drive Chain
      • Editor:Hangzhou Handun Machinery Co., LtdDate:2016-03-09 20:21 Click:


      Heavy Duty offset sidebar roller Chains




      Heavy-Duty Cranked Link Transmission Roller Chain manufactured to ISO 3512, the cranked plate designed for high impact, heavy load tranmission and frequent intermittent work application such as power drives, construction machinery, steel mill and conveyors; it operates under the most severe conditions at moderately high speeds.



      Chain Size:

      Chain No.
      Pitch
      Inner Width
      Roller Dia
      Plate Height
      Tension Strength
      2010
      63.50
      38.10
      31.75
      47.80
      250
      2512
      77.90
      39.60
      41.28
      60.50
      340
      2814
      88.90
      38.10
      44.45
      60.50
      470
      3315
      103.45
      49.30
      45.24
      63.50
      550
      3618
      114.30
      52.30
      57.15
      79.20
      760
      4020
      127.00
      69.90
      63.50
      91.90
      990
      4824
      152.40
      76.20
      76.20
      104.60
      1400
      5628
      177.80
      82.60
      88.90
      133.40
      1890
      WG781
      78.18
      38.10
      33
      45
      250.00
      WG103
      103.20
      49.20
      46
      60
      450.00
      WG103H
      103.20
      49.20
      46
      60
      500.00
      WG140
      140.00
      80.00
      65
      90
      1100.00
      WB10389
      103.89
      49.20
      46
      70
      1000.00
      WB9525
      95.25
      39.00
      45
      65
      600.00
      WB7900
      79.00
      39.00
      31.50
      54
      350.00
      WB7938
      79.38
      41.20
      40
      57.20
      500.00
      WB1198
      119.89
      44.00
      36.8
      45
      280.00


      Application:

      Asphalt:          Crane Crawler.
      Foundry:         Drum Drive
      Sugar Mill:      Roll Drive
                             Feed Roll
      Steel Mill:       Furnace door
                             Reclaimer for iron ore and coal
                             Draw Bench
      Refinery:         Drum Drive
      Mining:            Crusher
                              Drilling Machine (long hole blasting)
      Pulp & Paper:  Drum Drive
                               Barking Drum




      Related Products:

      Sprocket:  It is suggested to use our sprocket together with our heavy-duty cranked tranmission chain. When chains and sprockets articulate correctly, the life of the chain is extended. Our carbon steel sprockets are heat treated, provides long wear life and resists abrasion.


      -Handun Catalogue
      Heavy Duty Offset Sidebar Roller Chain
